Roots Blower

• Application
• Other, Pneumatic conveying, Wastewater treatment aeration, Cement, Power plants, Aquaculture, Chemical industries

• Capacity
• 50 - 10,000 m3/hr

• Color
• Metallic Grey/Black

• Dimension (L*W*H)
• Depends on Model; Commonly ranges from 500x300x350 mm upward

• Flow Rate
• 50 - 10,000 m3/hr

• Frequency (MHz)
• 50/60 Hz

• Life Span
• 10-15 years with regular maintenance

• Material
• other , Cast Iron/Steel body with High-Quality Alloy Steel Rotors

• Max Pressure
• 1.0 bar gauge

• Motor Power
• As specified, aligned with Power requirement

• Motor Speed
• 1450-2880 RPM (based on application)

• Noise Level
• <85 dB(A) @1 meter (with suitable silencers)

• Output Power
• Varies with application, up to 75 kW

• Power
• 3 to 75 kW (depends on size/capacity)

• Power Source
• Other, Electric Motor Driven

• Pressure
• Other, 0.1 - 1.0 bar gauge

• Pressure Range
• 0.1 - 1.0 bar

• Product Type
• Others, Positive Displacement Roots Blower

• Vaccum Range
• Up to -500 mmHg (varies with model)

• Voltage
• 380-440 V (3-phase standard industrial rating)

• Weight
• ~120-350 Kg (as per model size)

• Application
• Other, Aeration, Pneumatic Conveying, Wastewater Treatment, Printing, Food Processing

• Capacity
• 100 m3/hr to 1200 m3/hr

• Color
• Silver/Grey

• Dimension (L*W*H)
• Custom/Standard (Varies as per model)

• Flow Rate
• Variable as per requirement (range: 100-1200 m3/hr)

• Frequency (MHz)
• 50/60 Hz

• Life Span
• 8-10 Years (with Proper Maintenance)

• Material
• other , Aluminum Alloy

• Max Pressure
• 0.6 kg/cm2

• Motor Power
• As Per Model

• Motor Speed
• 2800 RPM

• Noise Level
• Below 75 dB

• Output Power
• As per Model

• Power
• 0.5 HP to 25 HP

• Power Source
• Other, Electric

• Pressure
• Other, 0.1 - 0.6 kg/cm2

• Pressure Range
• Up to 0.6 kg/cm2

• Product Type
• Others, Single Stage Ring Roots Blower

• Vaccum Range
• Up to -0.45 kg/cm2

• Voltage
• 220-415 V

• Weight
• Approx. 25-60 kg (Depends on model)
